Product Overview
Von Duprin electric strikes are known for their reliability, durability and security. The 6300 Series strike is designed to withstand abuse with its heavy-duty stainless steel certification construction is fully UL 1034 and UL 10C listed
he 6300 Series strike is designed for use with a variety of rim exit devices. As an electrified strike, it allows remote release of a locked door by activating a movable lip (keeper) using an entry/exit button or credential reader and can be a cost effective means for managing access. It is ideal for aftermarket applications and designed to install without modifying or altering the door frame.Designed for fail-secure (FSE) only mode, the 6300 Series strike achieves compliance with UL10C for 3-hour fire-rated openings. It also enables field- selectable 12 or 24 VDC with AC conversion optional.
To assure the proper selection of an electric strike on new applications, lockset compatibility charts are shown on the next page. When using a lockset not listed or when retrofitting a strike to an existing application, please contact Von Duprin Technical Support for application assistance.
Main Features
- Designed for use with rim exit devices
- Heavy-duty stainless steel construction in BHMA 630 satin finish
- Surface mounted - requires no alteration or cutting to existing frame
- Plug-in voltage connectors included for ease of installation and removal during strike servicing
- Non-handed design provides greater flexibility
- Suitable for interior and exterior doors
- UL 10C 3-hour fire-rated (fail secure only)
- UL 1034 listed for burglary-resistant electric door strikes
- UL 294 listed for access control system
- CSFM California State Fire Marshal listed
Specifications
- Compatible Door Lock Type: Cylindrical
- Color: Silver
- Input Voltage: 12V DC, 24V DC
- Material: Stainless Steel
- Security Configuration: Fail Secure
- Product Type: Electric Strike
- Product Series: 6300
- Application/Usage: Door
- Compatible Door Frame Type: Aluminum, Metal, Wood
- Country of Origin: US
- Depth: 0.75"
- Door Handling: Non-Handed
- Features: Surface Mount
- Height: 9.00"
- Input Current: 240mA
-
Package Contents:
- 6300 Electric Strike
- Plug-in Voltage Connectors
General Information
- Name: Von Duprin 6300 Series Electric Strike, Surface Mounted for Rim Exit Devices, Fail-Secure, Satin Stainless Steel
- Country of Origin: United States. Country of origin is subject to change.
