Vertiv GXT5-15KMVRT11UXLN Liebert GXT5 UPS-15kVA/15kW/208 and 120VAC|Online Rack/Tower Energy Star

$12,045

GXT5-15KMVRT11UXLN

The Vertiv Liebert GXT5 uninterruptible power supply (UPS) protects critical equipment against outages and every type of power disturbance. This 15kVA online double conversion UPS offers continuous power conditioning in centralized and edge locations. With unity power factor (1.0), it allows more connected loads saving space and costs. This tower/rack mount UPS has a built-in Vertiv RDU101 communications card with the free Vertiv Power Insight software for remote monitoring to help you make more informed decisions and faster event resolution. This 208V in/ 208 and 120V out single phase UPS has scalable runtime options with External Battery Cabinet (EBC) Autodetection to give extra runtime during an outage to support critical equipment. This battery backup is ENERGY STAR 2.0 certified and comes with a color/graphic LCD HMI display. It offers battery heath status and has optional Power Output Distribution (POD) selections with NEMA or IEC outlet receptacles.

Flexible, Online Double Conversion

The VertivTM Liebert® GXT5 UPS is an online double conversion UPS solution which offers premium power outage protection and continuous power conditioning in a compact and flexible deployment system. This single-phase UPS operates with high power efficiency is intended for both centralized and edge applications. It provides battery health status and replacement date prediction for intelligent battery health management. Available from 500VA to 20kVA, the GXT5 includes a rack mounting hardware kit and base for tower installation in open environments. Scalable runtime options with matching external battery cabinets and hot-swappable internal batteries offer additional flexibility when extended uninterrupted power is required. The 15kVA-20kVA UPS models include pre-installed Vertiv RDU101 SNMP/Webcard, a network management card with security and remote management capabilities that makes systems easy to deploy and simple to manage. With optional Vertiv LIFE Services, data center managers can reduce the risk of unexpected downtime through remote diagnostic and preventive monitoring. The Vertiv Liebert 15-20kVA GXT5 UPS includes:

  • Three-year comprehensive factory warranty for UPS and battery.
  • Rack/tower convertible systems that are easy to install, configure and operate.
  • High Output Power Factor of 1.0 (unity) ensures the maximum usable power to support the connection of more loads and IT equipment.
  • EPA Energy Star® 2.0 certified with high normal operating efficiency and ultimate efficiency with Vertiv’s active eco-mode.
  • User-friendly interface includes color graphic LCD with gravity sensing feature.
  • Optional power output distribution (POD) modules available with either NEMA or IEC receptacles.
GENERAL INFORMATION
Manufacturer
Vertiv
Manufacturer Part Number
GXT5-15KMVRT11UXLN
Brand Name
Liebert
Product Series
GXT5
Product Name
GXT5 15kVA Rack/Tower UPS
Product Condition
New
Packaged Quantity
1 Pack
Product Type
Dual Conversion Online UPS
TECHNICAL INFORMATION
Plug/Connector Type
Hardwired
Receptacle Type
Hardwired
Transfer Time
0 ns
Phase
Single Phase
Application/Usage
  • Mission Critical Equipment
  • Room
POWER DESCRIPTION
Load Capacity
15 kVA/15 kW
Input Voltage
  • 120 V AC
  • 230 V AC
Output Voltage
  • 120 V AC
  • 208 V AC
Waveform Type
Pure Sine Wave
MANAGEMENT
Bypass Switch
  • Manual
  • Automatic
  • Internal
CONTROLS/INDICATORS
Status Indicators
Alarm / Fault Indication
INTERFACES/PORTS
Serial Port
Yes
Modem (RJ-11)
No
Network (RJ-45)
Yes
USB (HID Compliant) Port
Yes
EPO Port
Yes
Modular Slots
1 x Expansion Slot
BATTERY INFORMATION
Battery Characteristics
Valve Regulated Lead Acid (VRLA)
Backup/Run Time (Full Load)
3 Minute
Backup/Run Time (Half Load)
9 Minute
PHYSICAL CHARACTERISTICS
Form Factor
Rack/Tower
Rack Height
11U
Height
19"
Width
16.9"
Depth
26.7"
Weight (Approximate)
396.60 lb
Shipping Height
46"
Shipping Width
27.10"
Shipping Depth
48"
Shipping Weight (Approximate)
518.80 lb
MISCELLANEOUS
Package Contents
  • GXT5 15kVA Rack/Tower UPS
  • 4 Post Fixed Rail Kit
  • Tower Stand
  • USB Cable
  • Quick Start Guide
  • Safety Instruction Manual
Additional Information
  • Emergency Power Off: Integrated EPO Contact
  • Switching Time: 0s
  • Auto Shutdown Software: Trellis Power Insight
  • Diagnostic LEDs: Alarm / Fault Indication
  • Hot Swappable: Yes
  • Status Indicators: LED/Full Color Graphic LCD
  • VGA: No
  • Dataline Protection: No
Energy Star
Yes
Environmentally Friendly
Yes
Environmental Certification
  • REACH
  • RoHS
Country of Origin
China
TAA Compliant
No
WARRANTY
Limited Warranty
3 Year
