Samsung Hanwha Techwin QND-8011 5M H.265 NW Dome Camera(Q mini)

$349.00 $400.00
Brand: Hanwha Techwin By SamsungReviews
5MP resolution
You save $51.00 (12%)
Available to order. Usually ships within 72 hours.
  • Free US shipping on this item.
  • 30-day returns counted from delivery. Return policy
  • Manufacturer's warranty from Hanwha Techwin By Samsung. Warranty
  • Need a quote? Add it to your cart and download a PDF quote, or ask for volume pricing.
D Questions about this product? Daniel and the team answer fast. 1-833-SILARIUS · Message us
More information View images
Reviews

The QND-8011 from Hanwha's Q mini Series affordable network camera line is a 5 Megapixel Super-Compact Indoor Dome network camera featuring WiseStream II, Hanwha's compression technology, triple codec H.265/H.264/MJPEG, 2.8mm lens, PoE, 120dB True WDR, IP42, IK08, defocus & tampering detection, Hallway View, and SD card slot (SD/SDHC/SDXC up to 128GB). The super-compact form factor perfectly blends into any environment, making it ideal for retail. The Wisenet Q mini series also features people counting business intelligence as well as real-time HDMI video output for public view monitor display.

  • Video
    Imaging Device 1/2.8" 5MP CMOS
    Effective Pixels 2592(H)x1944(V)
    Min. Illumination Color: 0.15Lux(F2.0, 1/30sec)
    Video Out HDMI: 1080p@30/25fps(60/50Hz)
    Lens
    Focal Length (Zoom Ratio) 2.8mm fixed focal
    Max. Aperture Ratio F2.0
    Angular Field of View H: 10.4.4°/ V: 76.7°/ D: 136.1°
    Focus Control Fixed
    Pan / Tilt / Rotate
    Pan / Tilt / Rotate Range 0˚~350˚ / 0˚~69˚ / 0˚~355˚
    Operational
    Camera Title Displayed up to 85 characters
    Day & Night Auto(Electrical)
    Backlight Compensation BLC, WDR, SSDR
    Wide Dynamic Range 120dB
    Digital Noise Reduction SSNR
    Motion Detection 4ea, polygonal zones
    Privacy Masking 6ea, rectangular zones
    Network
    Ethernet RJ-45(10/100BASE-T)
    Video Compression H.265/H.264: Main/High, MJPEG
    Resolution 2592 x 1944, 1920 x 1080, 1280 x 960, 1280 x 720, 800 x 600, 800 x 448, 720 x 576, 720 x 480, 640 x 480, 640 x 360
    Max. Framerate H.265/H.264: Max. 30fps/25fps(60Hz/50Hz)
    MJPEG: Max. 15fps/12fps(60Hz/50Hz)
    Smart Codec WiseStreamⅡ
    Video Quality Adjustment H.264/H.265: Target bitrate level control
    MJPEG: Quality Level control
    Bitrate Control H.264/H.265: CBR or VBR
    MJPEG: VBR
    Streaming Unicast(6 users) / Multicast
    Multiple streaming (Up to 3 profiles)
    Protocol IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP
    Security HTTPS(SSL) Login Authentication
    Digest Login Authentication
    IP Address Filtering
    User access log
    802.1X Authentication(EAP-TLS, EAP-LEAP)
    Edge Storage Micro SD/SDHC/SDXC 1slot 128GB
    Application Programming Interface ONVIF Profile S/G/T
    SUNAPI(HTTP API)
    Wisenet open platform
    Web Viewer Supported OS: Windows 7, 8.1, 10, Mac OS X 10.12, 10.13, 10.14
    Recommended Browser: Google Chrome
    Supported Browser: MS Explore11, MS Edge, Mozilla Firefox(Window 64bit only), Apple Safari(Mac OS X only)
    Memory 512MB RAM, 256MB Flash
    Environmental
    Operating Temperature / Humidity -10°C ~ +40°C (-14°F ~ +104°F) / Less than 90% RH
    Storage Temperature / Humidity -30°C ~ +60°C (-22°F ~ +140°F) / Less than 90% RH
    Certification IP42, IK08
    Electrical
    Input Voltage PoE(IEEE802.3af, Class2)
    Power Consumption PoE: Max 5W, typical 4W
    Mechanical
    Color / Material White / Plastic
    RAL Code RAL9003
    Product dimensions / weight Ø99x56mm(Ø3.9x2.2"), 165g
  • • The lastest product information / specification can be found at hanwha-security.com
    • Design and specifications are subject to change without notice.
    • Wisenet is the proprietary brand of Hanwha Techwin.

Shipping

Free US shipping on orders over $200. Orders under $200 ship at the rate shown at checkout. Oversized items ship by freight; we confirm the quote with you first.

Shipping policy

Returns

Return within 30 days of delivery. Opened items may carry an open-box fee of up to 30%, set by our QA team on inspection. Return shipping is paid by the customer.

Start a return

Damaged or wrong item?

Tell us within 3 days of delivery with photos and we'll make it right, with no fee.

Contact us

Hanwha Techwin By Samsung warranty

This product is covered by the manufacturer's warranty. We help you with the claim from start to finish.

Warranty details

Support from real people

Setup questions, compatibility, firmware: chat with a specialist or email info@silarius.com, Monday to Friday, 8am to 4pm ET.

Chat with us

Business accounts

Approved businesses can pay on Net 30 / PO terms after their second completed order.

Ask about terms

Frequently Asked Questions

What resolution does the Samsung Hanwha Techwin QND-8011 5M H.265 NW Dome Camera(Q mini) support?+
Check specs for exact resolution, frame rate, and compression format (H.264/H.265+).
Is it ONVIF-compatible?+
Most Hanwha Techwin By Samsung security products are ONVIF-compliant for integration with third-party VMS and NVR systems. Confirm the ONVIF profile in the datasheet.
Does it work outdoors?+
Outdoor-rated models carry IP66 or IP67 ratings. Verify the IP rating in the product specs before outdoor deployment.
What warranty does Silarius provide?+
Silarius provides manufacturer-backed warranty. Contact us at silarius.com for warranty claims and RMA requests.
Can I install it myself?+
Basic setups are DIY-friendly. For multi-camera or PoE switch configurations, professional installation is recommended.
