Product Overview
The DA11ADE is a plug and play device that is powered using either PoE (Power over Ethernet) from any PoE network switch or via local 12V power supply input.The DA11ADE also supports AES67 RTP audio transport and independent gain per channel for adjustment of the audio sensitivity as required.
Main Features
- Decodes a Dante digital signal to unbalanced or balanced 2 channel analogue audio
- Supports 44.1, 48 and 96 KHz sample rates at 24 Bit
- Configurable Dante device latency (supports 1,2 or 5ms configurable using Dante Controller)
- Independent output gain control per channel +18dBu to -10dBV
- Supports AES67 RTP audio transport
- Features Class 1 802.3af PoE for powering of product from any PoE switch
Specifications
-
Environmental Certification: CAN ICES-3 (B)/NMB-3(B), CE, FCC, RoHS
-
Height: 1.02"
-
Package Contents: 1 x DA11ADE, 1 x Quick Reference Guide
-
Power Source: PoE (Power over Ethernet)
-
Width: 1.85"
General Information
-
Name: Blustream DA11ADE Dante Audio Analog Decoder, PoE Powered
-
Country of Origin: China. Country of origin is subject to change.
