TEM Italy A07E1002 Integrated 2U 1000W FM Transmitter TEM Italy A07E1002 Integrated 2U 1000W FM Transmitter
TEM Italy A07E1002 Integrated 2U 1000W FM Transmitter
TEM Italy A07E1002 Integrated 2U 1000W FM Transmitter

TEM Italy A07E1002 Integrated 2U 1000W FM Transmitter

$5,409.82
Brand: TEM ItalyReviews
Available to order. Usually ships in 1–3 business days.
  • Free US shipping on this item.
  • 30-day returns counted from delivery. Return policy
  • Manufacturer's warranty from TEM Italy. Warranty
  • Need a quote? Add it to your cart and download a PDF quote, or ask for volume pricing.
D Questions about this product? Daniel and the team answer fast. 1-833-SILARIUS · Message us
More information View images
Reviews

OPERA plus 1000W FM 87,5/108MHz transmitter uses 1x1400W amplifier with 6^ generation LDMos technology, practically unbreakable.

The technical solutions adopted by our engineers are focused to assure energy saving (among the lowest) and high reliability. Settings, protections, telemetry are totally microprocessor controlled.

The installation and the maintenance of the equipment are respectively very fast and easy. These fully protected transmitters are indicated for use in unmanned stations.

Features:

  • ECO LINE - HIGH EFFICIENCY TRANSMITTER
  • Wideband circuits amplifiers with LDMOS technology
  • Built-in exciter with digital frequency synthesiser
  • Digital Stereo encoder, RDS encoder, AES-EBU input board (options)
  • Audio change-over built-in
  • Automatic fold-back ROS protection
  • Fold-back temperature protection
  • LCD display to check all operating parameters
  • 1x1400W amplifier in only one heat-sink for highest reliability
  • Switching-mode Power Supply -
  • Efficiency >95%
  • Sealed duct cooling air with blowers
  • Easy removable blowers
  • Harmonics filter & directional coupler built-in
  • GSM Telemetry & TCP/IP Webserver with SNMP/SMTP (option)
  • Headphone jack on front panel

Technical Specifications:

  • Operating Voltage: 240V AC ÷ 10%
  • Cooling system: forced air
  • AC Consumption: < 1340W
  • Operational Temperature Range: -5° to +50°C
  • Storage Temperature Range: -20° to +60°C
  • RF Output connector: DIN 7/16
  • RF Monitor connector: BNC
  • Dimension: 485x88,8x625mm
  • Weight: 14 kg
