Square Matters
The heavy-duty motor structure includes a large-diameter spider for less flex, longer life and superior accuracy. High-temp voice coil wire winding completes a powerful Comp motor that makes the most of every watt you give it.
Product Highlights:
- Dual Four-Ohm Voice Coils
- Injection-Molded Polypropylene Cone
- Patented Corner Ribs Minimize Distortion
- SoloKon™ 360-Degree Back Bracing
- Ribbed Santoprene Surround With Blue Surround Stitching
- UniPlate™ Back Plate And Pole Piece, Plus Perimeter Venting For Excellent Thermal Management
- Thick Tinsel Leads
- Large Ceramic Magnet
- Cast Aluminum Basket
- Satin-Nickel Plated, Spring-Loaded Speaker Terminals
Want setup help? Go to KICKERU for a free woofer & amplifier configuration app!
*The Solo-Baric L7S 15-Inch Subwoofer works best with a sealed or ported enclosure and 1,000 watts of recommended power.
| Thiele/Small Parameters |
| 44L7S124 T/S Parameters |
| Size (IN.,CM) |
| 12, 30.5 |
| Impedance (OHMS) |
| 4 DVC |
| Recommended Amplifier Power (watts RMS) |
| 750 |
| Peak Power (watts, per ANSI/CTA-2031-A) |
| 1500 |
| Sensitivity (dB 1w/1m) |
| 88.6 |
| Frequency Response (Hz) |
| 20-100 |
| Mounting Depth (IN.,CM) |
| 6-11/16, 16.9 |
| Mounting Cutout, Square (IN.,CM) |
| 11-1/16, 28.1 |
| Min Rec Sealed Box Volume (CU. FT., Liters) |
| 1.25, 35.4 |
| Max Rec Sealed Box Volume (CU. FT., Liters) |
| 2.0, 56.64 |
| Min Rec Vented Box Volume (CU. Ft., Liters)** |
| 1.75, 49.6 |
| Max Rec Vented Box Volume (CU. Ft., Liters)** |
| 3.25, 92.1 |
| What's in the box? |
| one 12-inch subwoofer, one owner's manual, two stickers |
