The Dymension CI™ MAX Series, Definitive Technology’s premier installed speaker line, leverages our most advanced acoustic innovations in discreet, adjustable in-ceiling and in-wall speakers. Dymension CI MAX in-ceiling speakers deliver precise sound for high-performance home theater and whole-home systems, with features like our patented pivoting woofer, flush-mount design, and robust weather protection. The series includes the Dymension CI DC-80 MAX SUR, an in-ceiling surround speaker that delivers expansive overhead sound in even the largest spaces.
Features
- Effortless, toolless installation; pre-construction brackets available
- Audiophile-quality sound in in-ceiling speakers
- Two speaker sizes for flexibility in power and placement
- DC-80 MAX SUR for expansive overhead surround sound
- Advanced crossover optimizes drivers for balanced sound
- Pivoting tweeters aim highs wherever you want them
- Patented pivoting BDSS™ woofer directs rich sound anywhere
- Tailor sound with a three-way high-frequency adjustment switch
- Low-profile, borderless design vanishes into any room
- Acoustically transparent paintable microperforated grille
- CI Series is IP55-rated for use outdoors and in high-humidity spaces
- Timbre-matched with Dymension™ and Mythos® speakers
| Product Dimensions (Diameter) |
11.80 in (299.8 mm) |
| Cut-Out Dimensions (Diameter) |
10.57 in (268.6 mm) |
| Mounting Depth |
5.34 in (135.7 mm) |
| Weight |
6.66 lbs (3.02 kg) |
| Grille Material |
Micro-Perforated Magnetic Grille |
| Tweeter |
(2) 1in Pivoting Aluminum Oxide Dome Tweeter |
| Midrange/Midbass |
8 in Mineral Filled Poly BDSS™ with Linear Response Waveguide™ |
| Frequency Response |
23 Hz–30 kHz (-10 dB)
36 Hz–25 kHz (-3 dB) |
| Nominal Impedance |
6Ω |
| Sensitivity |
85dB (2.83V/1m) |
| IP Rating |
IP55 |
| Included Accessories |
Grille, Literature Pack (QSG/
Registration Card/Warranty), Hole Cutting Guide |
