TX1152 fits the bill when applications that require the low-frequency extension of a 15“ woofer, with the outstanding pattern control of a larger, rotatable, 60 x 40 horn.
Features
- Designed for Club Sound, House of Worship, Pro Music, and other applications.
- DH3 1.25” (32 mm) diaphragm, 1” (25 mm)-exit pure titanium compression driver
- SMX2151 15” (381 mm) LF transducer with fully symmetric drive
- Advanced fourth-order crossover with HF protection
- 60° x 40° rotatable coverage pattern
- 100 dB sensitivity, 133 dB maximum SPL
- 500 W continuous, 2000 W peak power handling
- Pole mount for tripod use
- Six 3/8” threaded points for suspension
| Color |
Black |
| Input Connections |
Parallel Neutrik® NL4 |
| Speaker Type |
Fullrange |
| Frequency Response (-3 dB) |
55 - 20000 Hz
|
| Frequency Response (-10 dB) |
40 - 20000 Hz
|
| Internal Crossover |
Yes |
| Recommended High-Pass Frequency |
40 Hz
|
| Sensitivity 1 W/1 m |
100 dB
|
| Max. SPL/1m (calc) |
133 dB
|
Coverage
(Nominal -6 dB) H° |
60 ° |
Coverage
(Nominal -6 dB) V° |
40 ° |
| Rotatable Horn |
Yes |
| System Power Handling (Continuous/Program/Peak) |
500 Watts |
|
LF Transducer |
SMX2151 |
|
HF Transducer |
DH3 |
| Crossover Frequency |
1650 Hz
|
| Nominal Impedance (Passive) |
8 Ω |
| Minimum Impedance |
5.6 Ω |
| Enclosure Material |
Plywood and MDF with EVCOAT |
| Flying |
Yes |
| Suspension |
(6) 3/8-inch threaded inserts |
| Height |
776 mm (30.55") |
| Width |
446 mm (17.56") |
| Depth |
446 mm (17.56") |
| Weight Net |
27.8 kg (61.29 lbs) |
