APC SMT1000C APC Smart-UPS 120V 1000VA LCD Backup Battery & Surge Protector with SmartConnect LCD
Protect servers, switches, routers, and networking devices, with the APC SMT1000C. This Smart-UPS 120V 1000VA LCD Backup Battery with Smart Connect provides backup battery power in the event of a power outage while also safeguarding equipment from harmful power conditions such as spikes and surges.
Features
Included with the APC SMT1000C is a service-free cloud monitoring option accessible from any internet connected device. It also maximizes the life and performance of Ups machines by providing proactive advice and life cycle recommendations to allow users to remotely power the infrastructure from anywhere.
Great Make
An automatic green mode ensures that users are operating at the highest level of efficiency, and an intelligent battery management system maximizes performance. With a 700 watt power capacity and eight battery/surge protected outlets, the APC SMT1000C is ideal for homeowners and small-medium sized businesses.
APC®
For nearly four decades, APC has become the industry-standard for reliable power and physical IT infrastructure. Now the leading name in IT departments large and small and among our vast community of channel partners, our history of innovation has pushed our products into the global spotlight with infrastructure, management, and data security solutions protecting organizations around the world.
| Output Power Capacity |
700Watts / 1.0 kVA |
| Maximum Configurable Power (Watts) |
700Watts / 1.0 kVA |
| Nominal Output Voltage |
120V |
| Output Voltage Distortion |
Less than 5% |
| Output Frequency (sync to mains) |
50/60Hz +/- 3 Hz |
| Other Output Voltages |
110, 127 |
| Topology |
Line Interactive |
| Waveform Type |
Sine Wave |
| Output Connections |
(8) NEMA 5-15R (Battery Backup) |
| Transfer Time |
6ms typical : 10ms maximum |
| Nominal Input Voltage |
120V |
| Input Frequency |
50/60 Hz +/- 3 Hz (auto sensing) |
| Input Connections |
NEMA 5-15P |
| Cord Length |
6ft ( 1.83 meters ) |
| Input Voltage Range for Main Operations |
82-144V |
| Input Voltage Adjustable Range for Mains Operation |
75 - 154V |
| Number of Power Cords |
1 |
| Other Input Voltages |
110, 127 |
| Battery Type |
Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof |
| Typical Recharge Time |
3 hours |
| Expected Battery Life |
3-5 years |
| RBC Quantity |
1 |
| Interface |
SmartSlot, USB |
| Control Panel |
Multi-function LCD status and control console |
| Audible Alarm |
Alarm when on battery: distinctive low battery alarm : configurable delays |
| Surge Energy Rating |
680Joules |
| Filtering |
Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449 |
| Max Dimensions (H x W x D) |
8.62 inches (219 mm , 21.9 CM ) x 6.73 inches (171 mm , 17.1 CM ) x 17.28 inches (439 mm , 43.9 CM ) |
| Net Weight |
44.31 lbs. (12.5 KG ) |
| Shipping Dimensions (H x W x D) |
12.99 inches ( 330 mm , 33.0 CM ) x 12.99 inches (330 mm , 33.0 CM ) x 23.23 inches (590 mm, 59.0 CM) |
| Shipping Weight |
49.91 lbs. (22.64 KG ) |
| Color |
Black |
| Operating Temperature |
32 - 104 °F ( 0 - 40 °C ) |
| Operating Relative Humidity |
0 - 95 % |
| Operating Elevation |
0-10000ft (0-3000meters ) |
| Storage Temperature |
-15 - 45 °C |
| Storage Relative Humidity |
0-95% |
| Storage Elevation |
0-50000ft ( 0-15000meters ) |
| Audible noise at 1 meter from surface of unit |
41.0 dBA |
| Online Thermal Dissipation |
175.0 BTU/hr |
| Approvals |
CSA, CSA C22.2 No. 107.1, ENERGY STAR V1.0 (USA), FCC Part 15 Class B, ICES-003, UL 1778 |
| Equipment Protection Policy |
Lifetime : $150000 |
| Standard Warranty |
3 years repair or replace and 2 years for the battery |
| RoHS |
Compliant |
| REACH |
Contains no SVHCs |
